The large compass SILVA 125B/H can be installed in the bulkhead, the compass capsule protrudes only 32 mm into the cockpit. In addition, the compass is equipped with a scale for the angle of heel and a built-in red light. It is ideal for large sized motor- or sailboats.The compass is shockproof and suitable for all speed ranges, the forward and backward heel is unlimited. The maximum heeling angle is 45°. With its yellow gimbaled steering lines and damped 5° compass rose, it is very easy to read.With the magnet set 3640-310 (see accessories for SILVA boat compasses) the compass can be compensated.Apparent rose diameter 125 mm.The SILVA quality ensures durability and excellent readability; the capsule bowl is made from clear and scratch resistant acrylic. The combination of a sapphire jewel bearing and a hardened steel pivot minimizes friction, which in turn gives rapid and accurate movements. Silva marine compasses have a no-spin compass card is designed for perfect dampening and exact reading. You can trust that even when your boat is exposed to rough seas the gimballed suspension system makes sure the functionality is never disturbed hence you will always be able to read the compass accurately.
70P is a bulkhead mount compass designed for yachtsmen that demand absolute accuracy and a steady card in all conditions.The compass handles unlimited slope of the keel line and a 30° heeling angle. The curved lubber line enables swift and clear reading at a glance without parallax errors. With a main steering scale on the horizontal part and direct reading on the vertical edge.70P is ideal for boats with a sitting as well as a standing helmsman. It can be mounted at most angles and its compact size makes it suitable for smaller boats.The SILVA quality ensures durability and excellent readability; the capsule bowl is made from clear and scratch resistant acrylic. The combination of a sapphire jewel bearing and a hardened steel pivot minimizes friction, which in turn gives rapid and accurate movements. Silva marine compasses have a no-spin compass card is designed for perfect dampening and exact reading. You can trust that even when your boat is exposed to rough seas the gimballed suspension system makes sure the functionality is never disturbed hence you will always be able to read the compass accurately.
The compass SILVA 100B/H can be installed in the bulkhead, the compass capsule protrudes only 18 mm into the cockpit. In addition, the compass is equipped with a scale for the angle of heel and a built-in red light. It is ideal for small to medium sized sailboats. The compass is shockproof and suitable for all speed ranges, the forward and backward heel is unlimited. The maximum heeling angle is 45°. With its yellow gimbaled steering lines and damped 5° compass rose, it is very easy to read.Apparent rose diameter 100 mm.The SILVA quality ensures durability and excellent readability; the capsule bowl is made from clear and scratch resistant acrylic. The combination of a sapphire jewel bearing and a hardened steel pivot minimizes friction, which in turn gives rapid and accurate movements. Silva marine compasses have a no-spin compass card is designed for perfect dampening and exact reading. You can trust that even when your boat is exposed to rough seas the gimballed suspension system makes sure the functionality is never disturbed hence you will always be able to read the compass accurately.
CASSENS & PLATH ZETA/1 built-in spherical compass with solid brass housing. Available in polished brass or black lacquered.Steering compass with high display accuracy (according to ISO standard).The clear rose pattern with 5° graduation enables fatigue-free reading over long periods of time, even at night.Technical features:Shock and vibration resistantBuilt-in shadow pin for deviation control (azimuth bearing)Glare-free 12 volt red light illuminationwith factory certificate
The yacht compass MERKUR S-R can be mounted on the bulkhead or on the console with the bracket mount (please order separately).120 mm apparent rose diameter, weight 1.6 kg oscillation period >4,7 sec.The full sphere, solid construction with gimbaled inner hanger ensure smooth and precise reading under all conditions. Seawater resistant aluminium housing, anodised and black powder-coated, impact and scratch resistant mineral glass dome, clear 5° compass card with three lubber lines.Comes with 12 V lighting (24 V is optional).Top quality, 'Made in Hamburg': For more than 150 years, C. PLATH's quality compasses have been appreciated worldwide.
Plastic, matt black varnished case. Suited for every type of compass. Two magazines B and C to compensate with 2 magnets, that can be reversed calibrated. Usually the adjustment has to be performed by a professional. Shipment: 2 magazines 130 x 25 x 25 mm, detailed mounting instruction.
Modern, elegant spherical compass for bulkhead mounting. It is just as suitable for (fast) lifeboats as it is for sailing yachts or motor yachts. Available with black or white plastic housing. The compass is equipped with a clinometer, the rose has a diameter of 85 mm.Supplied with built-in, multi-voltage capable LED lighting (12V/24V).MED/SOLAS approval Class B (lifeboats/rescue boats). The certificate is enclosed with the compass.
Installable compass BETA/1 in a brass housing (painted black or white). Steering compass from the traditional manufacturer CASSENS & PLATH, with higher accuracy (pursuant to the ISO norms). The clear compass rose with 5° divisions allows the compass to be watched over long times without the viewer becoming tired, even at night. Shock and vibration proof. With a shadow indicator for controlling deviation (azimuth bearing), as well as an antiglare 12 volt red light. With certificate. Brass housing.
Installable compass in a brass housing (polished or black). Steering compass from the traditional manufacturer CASSENS & PLATH, with higher accuracy (pursuant to the ISO norms). The clear compass rose with 5° divisions allows the compass to be watched over long times without the watcher becoming tired, even at night. Shock and vibration proof. With a shadow indicator for controlling deviation (azimuth bearing), as well as an antiglare 12 volt red light. With certificate. Brass housing. Available painted black or polished. Fixed version DELTA for installation at the helm or in the deck.
100P is a bulkhead-mounted compass designed for sailboats and yachtsmen that demand absolute accuracy, a steady card in all conditions and high heeling angles. It is suitable for mast-mounting thanks to front reading, 30° heeling angle and three lubber lines for multi-angle reading. The main steering scale on the horizontal part and direct reading on the vertical edge make the 100P ideal for boats with a sitting as well as a standing helmsman. With its compact size, 100P will it fit in most spaces and boats.Apperant card diameter 100 mm.The SILVA quality ensures durability and excellent readability; the capsule bowl is made from clear and scratch resistant acrylic. The combination of a sapphire jewel bearing and a hardened steel pivot minimizes friction, which in turn gives rapid and accurate movements. Silva marine compasses have a no-spin compass card is designed for perfect dampening and exact reading. You can trust that even when your boat is exposed to rough seas the gimballed suspension system makes sure the functionality is never disturbed hence you will always be able to read the compass accurately.
125FTC is a flush mounted compass with an apparent scale size of 125 mm and a gimballed cradle.To be mounted in the steering column or control console.Comes with red illumination (for 12 V) and magnetic compensator.
The Ritchie Globemaster is a very popular sailing boat binnacle compass worldwide.For the classic yacht it is available with a traditional skylight hood made from polished brass. Specifications for the Ritchie Globemaster SK-615-EX: - 6" 2 degree flat card dial, - polished brass finish, - full internal gimbals, - built-in compensators, - frosted sunshade panel - hood rotates to allow positioning of the sunshade, - green 12 Volt NiteVu Power Lighting, - 5-year manufacturers warranty, Measurements: 308 x 205 x 252 mm, weight: 9 kg.
CASSENS & PLATH TYPE/51 - the flat glass compass with full cardanic suspension is a traditional lifeboat compass. It complies with ISO 25862.Made of brass, the housing is stove-enamelled grey, the ring and gimbal are black.The compass has a traditional compass card with a diameter of 100 mm and 5° graduation.A wooden storage box with sliding lid (Article-No. 3740-010) and a brass compass house with petroleum lighting (one-piece, Article-No. 3740-011 or two-piece -012) can be found further down on this page under "Accessories".
CASSENS & PLATH TYPE/51 - the flat glass compass made of brass with full cardanic suspension is a traditional lifeboat compass. It complies with ISO 25862.Made of brass, the housing is stove-enamelled black, the ring and gimbal are made of polished brass.The compass has a traditional compass card with a diameter of 100 mm and international 2° graduations.It is supplied in a wooden storage case with a sliding lid.This traditional brass lifeboat compass in a wooden box is also ideal as an elegant gift.
The CASSENS & PLATH IOTA/1 built-in spherical compass with its fully cardanic bearing is suitable as a steering compass for console or wall (bulkhead) mounting.The housing and the adjustable hood are made of brass and can be stove-enameled black or white or polished. Under the polished mineral glass bell is the fully gimbal-mounted, black counter-sight compass rose with 5° graduation. The apparent diameter of the rose is 100 mm.Supplied with factory test certificate and 12 volt red light illumination element.Technical features:Total/flange Ø: 143mmBearing: Fully cardanicApparent rose: Ø 100mmRolling clearance: /- 180°Stamp clearance: /- 180°A mounted B C compensation is recommended. You can find this under "Accessories".The IOTA/1 built-in spherical compass is also available with MED approval. The IOTA/2 compass is also available in a surface-mounted version. Both versions can be found under "Similar products".
The PLASTIMO DORIS is a traditional flat glass compass with full cardanic suspension.The white rose with 1° graduation has a diameter of 78 mm.The compass is supplied in a wooden box (152 x 152 x 100 mm) with a transparent Plexiglas lid. It can be placed anywhere in this box without an additional holder.Alternatively, the compass can of course also be installed in a different housing or a steering column.
Accurate and easy-to-read compass.May be used as steering or bearing compass.Comes with bracket and plastic case.Length 200mm, weight 300 g, colour white/blue.
Bulkhead compass with three yellow steering lines for sailing boats, motor sailors and larger motor yachts.The compass has unlimited forward and backward inclination. The heeling meter indicates up to a maximum of 45°.The apparent rose diameter is 100 mm.Scope of deliverySilva 102B/HRed light illumination (12 V)Protective cap
Built-in steering compass with three cardanic, yellow steering lines for motor or sailing yachts. The plastic compass can be installed in a steering column or in the (bridge) deck.The dampened double scale with its large digits allows accurate reading, even in heavy heeling seas. The apparent rose diameter is 100 mm.The integrated compensator makes it possible to compensate for magnetic interference.Scope of deliverySilva 100FCred light illumination (12 V)integrated protective cover (UV-resistant and shockproof)integrated compensator
